Specs
| Model | Deck Width | Engine | Horsepower | MSRP |
|---|---|---|---|---|
| SW-32-14FS | 32″ | Kawasaki® FS Series | 14 | $5,349 |
| SW-36A-14FS | 36″ | Kawasaki® FS Series | 14 | $5,399 |
| SW-48V-14FS | 48″ | Kawasaki® FS Series | 14 | $5,799 |
| SW-52V-15FS | 52″ | Kawasaki® FS Series | 15 | $6,499 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. | ||||
| Product Dimensions | 32″ SW | 36″ SW | 48″ SW | 52″ SW |
|---|---|---|---|---|
| Length | 70″ | 72″ | 76″ | 76″ |
| Width (chute down) | 43″ | 47″ | 60.5″ | 64.5″ |
| Width (chute in transport position) | 33″ | 37″ | 49″ | 53″ |
| Weight | 450 lb | 470 lb | 515 lb | 535 lb |
| General | |
|---|---|
| Drive System Type | Belt Drive with 5-Speed Peerless Transmission |
| Deck | |
| Cutting Widths | 32″, 36″, 48″ and 52″ |
| Cutting Height | 1.75″ to 4.5″ in .25″ increments |
| Reverse Ground Speed | 2 mph |
| Total Fuel Capacity | 5.5 gallons |
| Caster Tires | 9″ x 3.5″ |
| Drive Tires | 13″ x 5″-6″ (32″) 13″ x 6.5″-6″ (36″, 48″ and 52″) |
| Blade Engagement | Ogura MA-GT-EXM3X (110ft lb) Adjustable air-gap for extended life. |
| Drive System | |
| Spindles | Cast-iron housing with tapered roller bearings. |
| Parking Brake | Hand lever |
| Seat | n/a |
| Pumps | n/a |
| Motors | n/a |
| Deck Lift | n/a |
| Type | Standard (32″) Advantage (36″) Velocity Plus™ (48″ and 52″) |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. 32″ model features dual-plate. |
| Forward Ground Speed | Up to 6 mph |
