Specs
| Model | Deck Width | Engine | Horsepower | MSRP |
|---|---|---|---|---|
| SWZT-36H-14FS | 36″ | Kawasaki® FS Series | 14 | $6,499 |
| SWZT-48H-15FSE | 48″ | Kawasaki® FS Series – electric-start | 15 | $7,249 |
| SWZT-52H-18FSE | 52″ | Kawasaki® FS Series – electric-start | 18 | $7,649 |
| SWZT-61H-22FSE | 61″ | Kawasaki® FS Series – electric-start | 22 | $7,999 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. | ||||
| Product Dimensions | 36″ SWZT | 48″ SWZT | 52″ SWZT | 61″ SWZT |
|---|---|---|---|---|
| Length | 75.5″ | 75.5″ | 76.5″ | 80″ |
| Height | 44″ | 44″ | 44″ | 44″ |
| Tracking Width | 36.25″ | 41.5″ | 41.5″ | 41.75″ |
| Width (chute down) | 48.5″ | 60.5″ | 64.5″ | 73.5″ |
| Width (chute in transport position) | 37″ | 49″ | 53″ | 62″ |
| Weight | 550 lb | 585 lb | 605 lb | 700 lb |
| General | |
|---|---|
| Total Fuel Capacity | 5.5 gallons |
| Drive Tires | 18″ x 6.5″-8″ (36″) 18″ x 8.5″-8″ (48″, 52″ and 61″) |
| Caster Tires | 9″ x 6.5″-4″ |
| Seat | n/a |
| Drive System | |
| Drive System Type | Hydro-Gear ZT2800 Transaxle |
| Pumps | Internal Pump: 10 cc |
| Motors | Internal Motor: 16 cc |
| Forward Ground Speed | Up to 7 mph |
| Reverse Ground Speed | 3 mph |
| Parking Brake | Hand lever |
| Deck | |
| Cutting Widths | 36″, 48″, 52″ and 61″ |
| Type | Hero Cutter Deck |
| Cutting Height | 1.5″ to 4.5″ in .25″ increments |
| Deck Lift | Hand lever |
| Construction | Dual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles. |
| Spindles | Aluminum housing with sealed ball bearings. |
| Blade Engagement | Ogura GT1-BS03 (110 ft lb) Adjustable air-gap for extended life. |
