Specs
| Specification | Tow-Behind | |
|---|---|---|
| Model | TL20W-26CH-EFI | TL20W-33BV |
| Engine | Kohler® Command PRO® EFI, V-Twin, electric start | Briggs & Stratton® Vanguard™ BIG BLOCK™, V-Twin |
| HP* | 26.5 | 33 |
| Fuel Capacity / Tank | 5.5 gallons – plastic tank with built-in fuel gauge | 5.5 gallons – plastic tank with built-in fuel gauge |
| CFM Output | 4,680 | 4,680 |
| Frame Construction | All-steel, welded | All-steel, welded |
| Impeller Construction | 4-blade, 3/8″-thick blades, all-steel, welded | 4-blade, 3/8″-thick blades, all-steel, welded |
| Impeller Mounting | Tapered locking hub | Tapered locking hub |
| Impeller Diameter / Width | 20″ / 6.5″ | 20″ / 6.5″ |
| Blower Housing Construction | Removable back panel for easy impeller and wear plate access | Removable back panel for easy impeller and wear plate access |
| Blower Housing Width | 7.5″ | 7.5″ |
| Blower Housing Wear Plates | Standard: 1/4″-steel, replaceable | Standard: 1/4″-steel, replaceable |
| Intake Hose Specifications | 120″ length, 12″-diameter intake hose, 0.045 blue thermoplastic rubber, wire helix with wearstrip | 120″ length, 12″-diameter intake hose, 0.045 blue thermoplastic rubber, wire helix with wearstrip |
| Unit Mounting | Hitch: Class III minimum | Hitch: Class III minimum |
| Discharge Tube | Clear thermoplastic, 8″ diameter, 60″ length | Clear thermoplastic, 8″ diameter, 60″ length |
| Throttle Control | Commercial-grade, all-steel mechanicals, plastic debris cover | Commercial-grade, all-steel mechanicals, plastic debris cover |
| Highway Ready** | Yes – optional roadside package | Yes – optional roadside package |
| Axle | Heavy-duty Dexter Torflex® axle (2,000 lb) | Heavy-duty Dexter Torflex® axle (2,000 lb) |
| Tires | 205 / 75 R15 highway tires with steel wheels | 205 / 75 R15 highway tires with steel wheels |
| Trailer Width | 53.5″ | 53.5″ |
| Accessories | Light Kit, Roadside Kit | Light Kit, Roadside Kit |
| Height | 110″ | 110″ |
| Weight | 990 lb | 1,060 lb |
| Warranty | 2-Year Commercial; 2-Year Non-Commercial; 90-Day Rental | 2-Year Commercial; 2-Year Non-Commercial; 90-Day Rental |
| MSRP | $11,049 | $10,599 |
| * Engine power levels as rated by the manufacturer. Specifications and prices subject to change without notice. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. All models and accessories subject to availability. ** Reference your local regulations to ensure compliance. Contact your local Scag dealer for specific availability information. | ||
