Specs
| Model | Deck Width | Engine | Horsepower | MSRP |
|---|---|---|---|---|
| Gasoline Powered | ||||
| STTII-52V-26CV-EFI | 52″ | EFI – electronic fuel injection | 26 | $16,999 |
| STTII-61V-31DFI | 61″ | FD Series DFI – digital fuel injected, liquid-cooled | 31 | $20,499 |
| STTII-61V-33BV | 61″ | Vanguard™ BIG BLOCK™ | 33 | $17,199 |
| STTII-61V-38CH-EFI | 61″ | EFI – electronic fuel injection | 38 | $17,999 |
| STTII-61V-40BV-EFI | 61″ | Vanguard™ BIG BLOCK™ – electronic fuel injection | 40 | $18,749 |
| STTII-72V-31DFI | 72″ | FD Series DFI – digital fuel injected, liquid-cooled | 31 | $21,799 |
| STTII-72V-38CH-EFI | 72″ | EFI – electronic fuel injection | 38 | $18,999 |
| STTII-72V-40BV-EFI | 72″ | Vanguard™ BIG BLOCK™ – electronic fuel injection | 40 | $19,799 |
| Diesel Powered | ||||
| STTII-61V-25KBD | 61″ | – Diesel Powered, liquid-cooled | 25 | $24,099 |
| STTII-72V-25KBD | 72″ | – Diesel Powered, liquid-cooled | 25 | $25,399 |
| LP Powered | ||||
| STTII-52V-25CH-LP-EFI | 52″ | EFI – Propane Powered, electronic fuel injection | 25 | $18,799 |
| STTII-61V-25CH-LP-EFI | 61″ | EFI – Propane Powered, electronic fuel injection | 25 | $19,499 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. | ||||
| Product Dimensions | 52″ Turf Tiger Gas / Propane | 61″ Turf Tiger Gas / Propane / Diesel | 72″ Turf Tiger Gas / Diesel |
|---|---|---|---|
| Length | 80.5″ | 85.5″ / 85.5″ / 88″ | 89.5″ / 92″ |
| Width (chute down) | 64.5″ | 73.5″ | 83″ |
| Width (chute in transport position) | 53.75″ | 62.75″ | 73.75″ |
| Height (ROPS down) | 46.5″ / 52.5″ | 46.5″ / 52.5″ / 46.5″ | 46.5″ |
| Height (ROPS up) | 68″ | 68″ | 68″ |
| Weight | 1,418 lb / 1,486 lb | 1,496-1,538 lb / 1,606 lb / 1,709 lb | 1,556 lb / 1,739 lb |
| General | |
|---|---|
| Total Fuel Capacity | 12 gallons (Gas/Diesel) 33.5 lb (LP) |
| Drive Tires | 26″ x 12″-12″ (61″ and 72″) 26″ x 9.5″-12″ (52″) |
| Caster Tires | 13″ x 6.5″-6″ |
| Seat | 4-point iso-mounted torsion-spring suspension seat |
| Drive System | |
| Drive System Type | Dual Pump and Motor |
| Pumps | Hydro-Gear: 16 cc |
| Motors | Parker: 18 ci |
| Forward Ground Speed | 12 mph (Gas/LP) 10 mph (Diesel) |
| Reverse Ground Speed | 6 mph |
| Parking Brake | Adjustable foot-operated pedal. AUSCO disc brakes. |
| Deck | |
| Cutting Widths | 52″, 61″ and 72″ |
| Type | Velocity Plus™ |
| Cutting Height | 1.5″ to 6″ in .25″ increments |
| Deck Lift | Adjustable foot-operated pedal |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. |
| Spindles | Cast-iron housing with tapered roller bearings. |
| Blade Engagement | Adjustable air-gap for extended life. |
