Specs
| Model | Deck Width | Engine | Horsepower | MSRP |
|---|---|---|---|---|
| SVRII-32A-16FX | 32″ | Kawasaki® FX Series | 16 | $9,999 |
SVRII-32A-23BV  | 32″ | Vanguard™ | 23 | $10,099 |
| SVRII-36A-19FX | 36″ | Kawasaki® FX Series | 19 | $10,399 |
| SVRII-36A-23BV | 36″ | Vanguard™ | 23 | $10,999 |
| SVRII-48V-22FX | 48″ | Kawasaki® FX Series | 22 | $11,599 |
| SVRII-48V-23CV | 48″ | Kohler® Command PRO® | 23 | $11,199 |
| SVRII-48V-25CV-EFI | 48″ | Kohler® Command PRO® EFI – electronic fuel injection | 25 | $11,299 |
| SVRII-52V-23FX | 52″ | Kawasaki® FX Series | 23 | $11,999 |
| SVRII-52V-25CV-EFI | 52″ | Kohler® Command PRO® EFI – electronic fuel injection | 25 | $11,499 |
| SVRII-52V-26FT-EFI | 52″ | Kawasaki® FT Series EFI – electronic fuel injection | 26 | $11,999 |
| SVRII-52V-26FT-EFI-NFT | 52″ | Kawasaki® FT Series EFI – electronic fuel injection | 26 | $13,499 |
| SVRII-52V-37BV-EFI | 52″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 37 | $13,399 |
| SVRII-61V-26CV-EFI | 61″ | Kohler® Command PRO® EFI – electronic fuel injection | 26 | $12,749 |
| SVRII-61V-38CV-EFI | 61″ | Kohler® Command PRO® EFI – electronic fuel injection | 38 | $13,499 |
| SVRII-61V-38FX-EFI | 61″ | Kawasaki® FX Series EFI – electronic fuel injection | 38.5 | $13,899 |
| SVRII-61V-38FX-EFI-NFT | 61″ | Kawasaki® FX Series EFI – electronic fuel injection | 38.5 | $15,399 |
| SVRII-61V-40BV-EFI | 61″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 40 | $14,099 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. | ||||
| Product Dimensions | 32″ V-Ride II | 36″ V-Ride II | 48″ V-Ride II | 52″ V-Ride II | 61″ V-Ride II |
|---|---|---|---|---|---|
| Length | 65.25″ | 65.25″ | 67.5″ | 69.5″ | 72.75″ |
| Tracking Width | 32″ | 36″ | 48″ | 48″ | 48″ |
| Width (chute down) | 43″ | 47.75″ | 61.25″ | 65.25″ | 73.5″ |
| Width (chute in transport position) | 33.75″ | 37.25″ | 49.75″ | 53.75″ | 62.75″ |
| Height | 47″ | 47″ | 47.25″ | 47.25″ | 47.25″ |
| Weight | 818 lb | 832 lb | 1,015 lb | 1,000-1,022 lb | 1,127-1,173 lb |
| General | |
|---|---|
| Total Fuel Capacity | 5 gallons (32″) 6.75 gallons (36″) 8 gallons (48″, 52″, and 61″) |
| Drive Tires | 20″ x 6.5″-10″ (32″) 20″ x 8″-10″ (36″) 24″ x 9.5″-12″ (48″ and 52″) 24″ x 12″-12″ (61″) |
| Caster Tires | 11″ x 4″-5″ (32″ and 36″) 13″ x 5″-6″ (48″ and 52″) 13″ x 6.5″-6″ (61″) |
| Seat | Extra-large comfort cushion |
| Drive System | |
| Drive System Type | Dual Pump and Motor |
| Pumps | Hydro-Gear 10 cc (32″ and 36″) Hydro-Gear 12 cc (48″, 52″, and 61″) |
| Motors | Parker 12 ci (32″ and 36″) Parker 14 ci (48″, 52″ and 61″) |
| Forward Ground Speed | 8.5 mph (32″ and 36″) 10.5 mph (48″, 52″ and 61″) |
| Reverse Ground Speed | 5 mph |
| Parking Brake | Hand lever |
| Deck | |
| Cutting Widths | 32″, 36″, 48″, 52″ and 61″ |
| Type | Advantage (32″ and 36″) Velocity Plus™ (48″, 52″, and 61″) |
| Cutting Height | 1.5″ to 4.5″ in .25″ increments |
| Deck Lift | Hand lever |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. 32″ model features dual-plate. |
| Spindles | Cast-iron housing with tapered roller bearings. |
| Blade Engagement | Ogura GT3.5 (250 ft lb) – (61″) Adjustable air-gap for extended life. |
