Specs
| Product Specification | Windstorm |
|---|---|
| Model | WS23-37BV-EFI |
| Total Fuel Capacity | 8 Gallons |
| Engine | Briggs Vanguard™ BIG BLOCK EFI |
| Horsepower | 37 HP |
| CFM Output | Effective CFM – 6,000 Theoretical Peak CFM – 7,500 |
| Electric Clutch | Ogura GT3.5 (250 ft lb) with Softstart Electric Clutch Control |
| Frame Construction | All-steel, welded 10-gauge |
| Impeller Construction | All-steel, welded, 8-blade, dynamically balanced |
| Impeller Mounting | Tapered locking hub |
| Impeller Diameter / Width | 23″ / 8.5″ |
| Blower Housing Construction | All-steel, welded, 12-gauge front and side housing plate and 10-gauge back housing plate |
| Blower Housing Width | 10″ |
| Blower Tilt Angle | 16 degrees of total vertical tilt; 180 degrees of left/right horizontal rotation |
| Handlebar | n/a |
| Vibration Control | n/a |
| Discharge Opening | 69 square inches |
| Left / Right Discharge Control | Nozzle Direction System offers up to 180 degrees of rotation. |
| Discharge Angle Control | Yes – mechanical lever |
| Axle | n/a |
| Front Wheel(s) | 13″ x 5″-6″, flat-free |
| Rear Wheels | 24″ x 12″-12″, 4-ply |
| Accessories | Light Kit, Chrome Wheel Covers, Air Filter Monitor |
| Length | 71.5″ |
| Width | 51″ |
| Height | 47.25″ |
| Weight | 943 lb |
| Warranty | 2-Year Commercial; 2-Year Residential; 90-day Rental |
| MSRP | $14,349 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. | |
