Specs
| Adjustable Discharge Baffle | Standard, Tools-Free |
|---|---|
| Adjustment | 5 point adjustment on rear shocks |
| Air Filter | Heavy-Duty Canister Air Cleaner |
| Armrests | Standard |
| Blade Tip Speed | 18,500 ft/min / 5,638 m/min |
| Blades | 0.204 in. (0.5 cm) heat-treated steel |
| Box Dimensions | 91 in. x 70.25 in. x 52 in. / 231.1 cm x 178.4 cm x 132.1 cm |
| CARB Compliant | Not CARB Compliant |
| Carrier Frame | 3 in. x 1.5 in. x 10 gauge (7.6 cm x 3.8 cm x 10 gauge) |
| Caster Tires | 13 in. x 6.5 in. - 6 in. (33 cm x 16.5 cm - 15.2 cm) Flat-Free Semi-Pneumatic |
| Clutch | Electromagnetic |
| Comfort Platform | MyRIDE® Suspension System |
| Deck Design | 80-Grade 7-gauge 60" (152 cm) TURBO FORCE® w/bull-nose bumper |
| Deck Material | 7 Gauge Steel |
| Deck Size | 60 in / 152 cm |
| Discharge Chute | Rubber |
| Drive System | Unitized Pumps 16cc and Wheel Motors 17.1 cir |
| Drive Tires | 24 in. x 12 in. - 12 in. (61 cm x 30.5 cm - 30.5 cm) |
| Engine | 31 hp* (23.12kW) Kawasaki® FX921V 999 cc |
| Engine Brand | Kawasaki |
| Engine Displacement (cc) | 999 cc |
| Engine Horsepower | 31.0 hp |
| Forward Ground/Transport Speed | Up to 11.5 mph / 18.5 kph |
| Front Bumper | Reinforced Bull-Nose |
| Fuel Capacity | 12 gal. / 45.4 L / 48 Qt. |
| Fuel Type | Gasoline |
| Height of Cut | 1.0 - 5.5 in. / 2.5 - 14.0 cm |
| Hour Meter | Standard |
| Hydraulic Fluid | Premium synthetic |
| ISO Mounts | Qty 4, 2.5 in. 3-D isolation mounts |
| Platform Travel | 3.6 in / 9.1 cm |
| Product Type | Zero Turn Mowers |
| Roll-Over Protection System (ROPS) | Folding; Standard |
| Seat | Handcrafted Deluxe Suspension Seat with Arm Rests Featuring Bullhorn Accent |
| Shocks | 1 Front Center / 2 Rear |
| Spindle Bearings | Maintenance-free |
| Spindle Housing | 9 in / 22.9 cm Diameter Cast Aluminum |
| Start Type | Electric |
| Steering Controls | 1-5/8" (4.1 cm) Diameter Grips; Adjustable, Dampened |
| Steering Dampeners | Standard Dampers |
| Weight | 1,271 lbs / 576.5 kg |
